Machining centre

The travel blocks and the machine bed are coupled together rigidly via preloaded HIWIN heavy-duty roller guides in the RG series. A water-cooled linear motor from the LMFA series is used as a powerful precision drive. The ready-to-connect, integrated water cooling system conducts away the heat of the motor via the existing cooling lubricant system in order to ensure a constant machine temperature.




Requirements:
  • Maximum rigidity
  • Play-free drive
  • Best synchronism
  • High load-bearing capacity

HIWIN components:
  • LMFA linear motors
  • Water-cooled
  • Peak force: 21,000 N
  • RG35 and RG45 roller guides
